Product Description

2 * 8 Port RJ 45 Jack, Shielded 16port RJ45 Connector J2042H3B J2045H3C J2039H3C 0853-2X8R-69
Shielded 16port RJ45 Connector Banner 2 * 8 Port RJ 45 Jack Shielded 16port RJ45 Connector 16port RJ45 Connector Specification Banner
Part Number RJ45 connector
Application-LAN ETHERNET(NON POE)
AutomDX YES
Bst Circuit YES
Configuration RX T,C
Configuration TX T,C
Contact Mating Area Plating GOLD 6u"/15u"/30u"
Cores Per Port 8
Diodes NO DIODES
LED Option WITH LEDS
Latch Up/Down
Number of Ports 2x8
PCB FR4
PCB Mount Angle SIDE ENTRY
PCB Retaining Post T POST
Pin Type THT SOLDER
RoHS Compliant YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search YES
Shield EMI Tabs Shield, EMI Finger
Speed 10/100/1000 Base-T
Temperature -40°C ~ 85°C
Turns Ratio RX 1CT:1
Turns Ratio TX 1CT:1
RJ45 Jack Mechanical Drawing
Preferred Supplier Of TI, Samsung, Cisco, Siemens ...
RJ45 Pin Layout Diagram
