| Technical Specifications | |
|---|---|
| Part No. | LS-SM552G-80C |
| Form Factor | SFP |
| Max Data Rate | 2.5Gbps |
| Wavelength | 1550nm |
| Max Cable Distance | 80km |
| Connector | Duplex LC |
| Media | SMF |
| Transmitter Type | DFB |
| Receiver Type | PIN |
| TX Power | -2 ~ 3dBm |
| Receiver Sensitivity | < -28dBm |
| EMC (Electro Magnetic Compatibility) | Supported |
| DDM/DOM | Supported |
| Protocols | MSA Compliant |
| Temperature Range | 0 to 70°C / -40 to 85°C |
| Warranty | 5 Years |
| Sample | Available |
| Part Number | Data Rate | Wavelength | Distance | Media | DDM |
|---|---|---|---|---|---|
| LS-MM852G-S3C | 2.5Gbps | 850nm | 300m | Multi-mode | Yes |
| LS-MM852G-S5C | 2.5Gbps | 850nm | 550m | Multi-mode | Yes |
| LS-SM312G-02C | 2.5Gbps | 1310nm | 2km | Single Mode | Yes |
| LS-SM312G-10C | 2.5Gbps | 1310nm | 10km | Single Mode | Yes |
| LS-SM312G-15C | 2.5Gbps | 1310nm | 15km | Single Mode | Yes |
| LS-SM312G-20C | 2.5Gbps | 1310nm | 20km | Single Mode | Yes |
| LS-SM552G-20C | 2.5Gbps | 1550nm | 20km | Single Mode | Yes |
| LS-SM312G-40C | 2.5Gbps | 1310nm | 40km | Single Mode | Yes |
| LS-SM552G-40C | 2.5Gbps | 1550nm | 40km | Single Mode | Yes |
| LS-SM552G-80C | 2.5Gbps | 1550nm | 80km | Single Mode | Yes |
We provide end-to-end DWDM devices along with almost all optical components - from active modules to passive optical devices, including optical amplifiers (EDFA & RFA), Mux & Demux, OPM, ROADM, MCS, OLP, OTDR, and more.
To meet the demands of massive data transmission in modern data centers, we offer a robust series of high-speed optical modules with data rates spanning from 10G up to 800G, delivering reliable optical interconnection solutions for large-scale applications.
Our high-reliability products utilize mature, efficient lasers and mainstream chip solutions. The architecture includes Dark Fiber, WDM, Radio over Fiber, High Speed, Mid-haul, and Back-haul links to cover various network deployment scenarios.
Targeting global telecommunication builders, our FTTx optical fiber access solutions cover all-optical as well as optical-copper hybrid systems and related access devices.
To keep networks running safely and efficiently, we provide optical cable operations and maintenance systems that integrate optical line protection (OLP) and real-time optical line monitoring (OLM) technologies.
Our facility is a specialized manufacturer of magnetic telecom and network components, certified by ISO9001:2000, RoHS, REACH, CE, and UL. We utilize advanced manufacturing tools and testing equipment imported from leading global suppliers. Since establishing our setup in 1997, our production infrastructure delivers reliable, large-volume capacity of 3000K units per month, supporting quick lead times.
Additionally, we specialize in a comprehensive line of optical modules for fixed and wireless networks, carrier Ethernet, WDM layouts, and data communication systems. We also engineer high-speed optical interconnect equipment geared toward cloud servers and ultra-broadband environments, designing, testing, and distributing these high-tech components globally.
